Equipped with TC-135 or TC-135A digital control
panel
Model：LT-40,LT-50,LT-60,LT-70,LT-80,LT-90,LT-105,LT-120,LT-150.
The shell is made of electrolytic plate with spray,
anti-corrosion and durable. Using TC-135 control panel, the machine
will automatically turn off after 45 minutes, the temperature can
be automatically controlled within 35-55 ° C (95-131 ° F) range ,
digital display temperature; Using the TC-135A control panel can
automatically control the temperature within 35-55 ° C (95-131 ° F)
range, but can also set up automatic shutdown time within 1-60
minutes , digital display temperature and time. The model is
suitable for families and small sauna clubs to use, with the
European CE certification and China Import and Export Commodity
Inspection certificate of inspection.
Parameters:
|
Model |
Power kw |
Power supply (50/60Hz) |
Power wire (copper) N*mm2 |
Dimensions cm |
Packing size cm |
Gross weight kg |
|
|
Voltage V |
Current A |
||||||
|
LT-40 |
4.0 |
220-240V~ |
18.2 |
3*2.5 |
39.5*15.3*31.3 |
53.5*21*41 |
9 |
|
LT-50 |
5.0 |
220-240V~ |
22.7 |
3*2.5 |
|||
|
LT-60 |
6.0 |
220-240V~ |
27.3 |
3*4.0 |
|||
|
380-415V3N~ |
9.1 |
5*1.5 |
|||||
|
LT-70 |
7.0 |
220-240V~ |
31.8 |
3*6.0 |
44.5*18.2*31.3 |
53.5*21*41 |
11 |
|
380-415V3N~ |
11.4 |
5*2.5 |
|||||
|
LT-80 |
8.0 |
220-240V~ |
36.4 |
3*6.0 |
|||
|
380-415V3N~ |
13.6 |
5*2.5 |
|||||
|
LT-90 |
9.0 |
380-415V3N~ |
13.6 |
5*2.5 |
|||
|
LT-105 |
10.5 |
380-415V3N~ |
15.9 |
5*2.5 |
50*20*52 |
54*25*61 |
18 |
|
LT-120 |
12.0 |
380-415V3N~ |
18.2 |
5*2.5 |
|||
|
LT-150 |
15.0 |
380-415V3N~ |
22.7 |
5*2.5 |
|||
|
Notice ：LT series commone type steam generator comes with high house cover and couples pieces heating elements, automatical draining function and 9-12KW single phase 220V-240V need to make specially. |
|||||||
