Equipped with R30 or TM60A
digital control panels
Model：AR4C,AR5C,AR6C,AR7C,AR8C,AR9C.
The shell is made of electrolytic
plate with spray, anti-corrosion and durable. Using the TM60A
control panel can automatically control the temperature within
35-55 ° C (95-131 ° F) range, but can also set up automatic
shutdown time within 1-60 minutes , digital display temperature and
time. The model is suitable for families and small sauna clubs to
use, with the European CE certification and China Import and Export
Commodity Inspection certificate of inspection.
|
Model |
Power kW |
Power supply (50/60Hz) |
Power wire (copper) N*mm2 |
Dimensions cm |
Packing size cm |
Gross weight kg |
|
|
Voltage V |
Current A |
||||||
|
AR4C |
4.0 |
220-240V～ |
18.2 |
3*2.5 |
39.5*15.3*31.3 |
53.5*21*42.5 |
9 |
|
AR5C |
5.0 |
220-240V～ |
22.7 |
3*2.5 |
|||
|
AR6C |
6.0 |
220-240V～ |
27.3 |
3*4.0 |
|||
|
380-415V3N～ |
9.1 |
5*1.5 |
|||||
|
AR7C |
7.0 |
220-240V～ |
31.8 |
3*6.0 |
44.5*18.2*31.3 |
53.5*21*42.5 |
11 |
|
380-415V3N～ |
11.4 |
5*2.5 |
|||||
|
AR8C |
8.0 |
220-240V～ |
36.4 |
3*6.0 |
|||
|
380-415V3N～ |
13.6 |
5*2.5 |
|||||
|
AR9C |
9.0 |
380-415V3N～ |
13.6 |
5*2.5 |
|||
|
AR10.5C |
10.5 |
380-415V3N～ |
15.9 |
5*2.5 |
50*20*52 |
64*25.5*60.5 |
18 |
|
AR12C |
12.0 |
380-415V3N～ |
18.2 |
5*2.5 |
|||
|
AR15C |
15.0 |
380-415V3N～ |
22.7 |
5*2.5 |
|||
|
Notice ：AR series Economic steam generators come with one group of heating elements and stanard manual drain valve. Auto drain valve could be installed on request. |
|||||||
